CYM5(EZC) Moulded Case Circuit Breaker

  • Place of Origin: Zhejiang, China
  • Type: Moulded Case
  • Poles Number: 1P/2P/3P
  • Standard: IEC 60947-2
  • Product description: CYM5 MCCB is simple and universal solution to fit all the needs in terms of low voltage protection.
  • INQUIRY

Application

CYM5 MCCB is simple and universal solution to fit all the needs in terms of low voltage protection.

Specification

Type

CYM5/EZC60E

CYM5/EZC100F

CYM5/EZC100H

CYM5/EZC250H

Number of Poles

3

3

3

3

Rated Current, In(A)

15, 20, 25, 30, 40, 50, 60

15, 20, 25, 30, 40, 50, 60, 75, 80, 100

15, 20, 25, 30, 40, 50, 60, 75, 80, 100

125, 160, 225, 250

Rated Operating Voltage Ue(V), AC50/60Hz

500

500

500

500

Rated Insulation Voltage Ui(V)

500

500

500

500

Rated Uimp (kV)

6

6

6

6

Breaking Capacity (kA ms), IEC60947-2

Icu, AC

220/240V

10

25

50

85

380V

7.5

10

30

18

400V

7.5

7.5

20

15

Ics%, Icu

220/240V

25%

25%

25%

25%

380V

25%

25%

25%

25%

400V

25%

25%

25%

25%

Breaking Capacity (kA), NEMA-ABI, HIC

AC

240V

-

-

25

25

480V

-

-

10

10

Mechanical Life (times)

8500

8500

8500

8500

Electrical Life (times)

4000

4000

4000

4000

Over Current Protection (A)

Thermal-Magnetic Protection

Fixed

Fixed

Fixed

Fixed

Electronic Protection

Fixed

Fixed

Fixed

Fixed
